◎Properties
Waveform steel fiber is in line with US ASTM A820 type l and China jG/3064 criteria Fiber was rolled and pressurized into a waveform which could increase its anchor strength in reinforeed concrete and the concrete 's bending tensile strength andbending malleability it has high tensile strength and is good for concrete heavy agitation and casting construction
◎ Applications
| Construction projects | Housing construction, ready-made pile, framework node, roof and underground |
| Pipeline projects | Centrifugal tube. Wbrated&extruded tube, pumptube; steel fiber conrete pressure pipesteel liner |
| Highway& bridge projects | Box arch bridge and ring. Continuous box bean, bridge surface |
| Tunnel and pit projects | Hydraulic tunnel lining, pit channel, rail way highway funnel lining |
| Road and airport road surface Road surface | Road surface, road surface in congealed area, airport road surface |
| Railway projects | Prestressed railway sleeper and double railway sleeper |
| Hydraulic and electrohydraulic project | Location of water scouring abrasion, throttlevalve |
| Port terminal and marine projects | Steel pipe pile corrosion resist ntoating, terminal utilities and submarine concrete facilities.Brake,tank,aqueduct,large dam infiltartion preventive faceplate |
| Others | heavyloaded industrial workshop building group and warehouse group thin-walledreservoirstructure/bin, maintenance and reinforcement projects, buried cable/pipe duct well cover sewage cover |
◎Grade and specifications Model: SUS-1250
| Fiber Equivalent Diameter D(mm) | Fiber Length L(mm) | Aspect Ratio L/D | Height of Waveform H(mm) | Tensile Strength (MPa) | Fiber Content (根/kg) |
| 1.15 | 50 | 42 | 1.1 | ≥700 | 2900 |
◎ Package
Compound packaging paper bag, 25kg per bag, 10000kg(40packs) per tray
◎ Reference criterion
JGT3064-1999《 Steel Fiber Concrete》
ASTMO94《 Ready-mixed Concrete criterion》
CECS 38:92 《Steel Fiber Concrete structural design& code of practice》
ASTM C1116《Norm of Steei Fiber Concrete and shoterete》
ASTM C1018 《Steel Fiber Concrete flexing toughness and its initially cracked strength standard experiment》
◎Properties
Waveform steel fiber is in line with US ASTM A820 type l and China jG/3064 criteria Fiber was rolled and pressurized into a waveform which could increase its anchor strength in reinforeed concrete and the concrete 's bending tensile strength andbending malleability it has high tensile strength and is good for concrete heavy agitation and casting construction
◎ Applications
| Construction projects | Housing construction, ready-made pile, framework node, roof and underground |
| Pipeline projects | Centrifugal tube. Wbrated&extruded tube, pumptube; steel fiber conrete pressure pipesteel liner |
| Highway& bridge projects | Box arch bridge and ring. Continuous box bean, bridge surface |
| Tunnel and pit projects | Hydraulic tunnel lining, pit channel, rail way highway funnel lining |
| Road and airport road surface Road surface | Road surface, road surface in congealed area, airport road surface |
| Railway projects | Prestressed railway sleeper and double railway sleeper |
| Hydraulic and electrohydraulic project | Location of water scouring abrasion, throttlevalve |
| Port terminal and marine projects | Steel pipe pile corrosion resist ntoating, terminal utilities and submarine concrete facilities.Brake,tank,aqueduct,large dam infiltartion preventive faceplate |
| Others | heavyloaded industrial workshop building group and warehouse group thin-walledreservoirstructure/bin, maintenance and reinforcement projects, buried cable/pipe duct well cover sewage cover |
◎Grade and specifications Model: SUS-1250
| Fiber Equivalent Diameter D(mm) | Fiber Length L(mm) | Aspect Ratio L/D | Height of Waveform H(mm) | Tensile Strength (MPa) | Fiber Content (根/kg) |
| 1.15 | 50 | 42 | 1.1 | ≥700 | 2900 |
◎ Package
Compound packaging paper bag, 25kg per bag, 10000kg(40packs) per tray
◎ Reference criterion
JGT3064-1999《 Steel Fiber Concrete》
ASTMO94《 Ready-mixed Concrete criterion》
CECS 38:92 《Steel Fiber Concrete structural design& code of practice》
ASTM C1116《Norm of Steei Fiber Concrete and shoterete》
ASTM C1018 《Steel Fiber Concrete flexing toughness and its initially cracked strength standard experiment》
